ACTIVA
Specifications
Body Dimensions
Length |
1833 mm |
Width |
697 mm |
Height |
1156 mm |
Wheel Base |
1260 mm |
Ground Clearance |
|
Seat Length |
|
Kerb Weight |
|
Fuel Tank Capacity |
5.3 L |
Engine
Type |
Fan Cooled, 4 Stroke, SI Engine |
Displacement |
109.51 cc |
Max Net Power |
5.73 kW @ 8000 rpm |
Max Net Torque |
8.79 Nm @ 5250 rpm |
Fuel System |
PGM-Fi |
Compression Ratio |
10.0:1 |
Air Filter Type |
Viscus Paper Filter |
Starting Method |
Std&Dix:kick/self |
Transmission
Clutch Type |
Automatic |
Tyres & Brakes
Tyre Size (Front) |
90/90-12 54j |
Tyre Size (Rear) |
90/100-10 53j |
Tyre Type (Front) |
Tubeless |
Tyre Type (Rear) |
Tubeless |
Brake Type & Size (Front) |
Drum |
Brake Type & Size (Rear) |
Drum |
Frame & Suspension
Front |
Telescopic |
Rear |
3-Step Adjustable Suspention unit swing |
Electricals
Battery |
12V 3.0 AH(MH) |
Head Lamp |
Std HALOGEN &Dix LED |
